Product introduction
A light truck van is a cargo vehicle with a total mass within a specified range (usually between 1.8 and 6 tons) and has a closed van.
- Features:
Cargo capacity: able to meet certain cargo transportation needs.
Box structure: provides better protection for the goods to prevent the goods from being affected by the external environment. - Flexibility: Suitable for short distance transportation in cities and suburbs.
- Purpose:
Urban logistics distribution, such as express delivery, daily necessities and other transportation.
Commercial goods transportation, such as small equipment, building materials, etc. - Structure:
- Body: made of metal material, with a certain strength and sealing.
- Chassis: Carries body and cargo weight.
- Power: Usually equipped with diesel or gasoline engines, power performance to meet the daily transportation needs.
Product specification
|
Truck Model
|
ZZ1107D3815D1
|
|
|
Driving Type
|
4×2
|
|
|
Dimension(Lx W xH)(mm)
|
6995x2400x3250
|
|
|
Cargo Body Size (LxWxH)
|
5150x2150x2000
|
|
|
Cargo Body Thickness
|
Bottom:3mm Side:1.5mm
|
|
|
Approaching angle/Departure angle(°)
|
27/22
|
|
|
Wheel base (mm)
|
3800
|
|
|
Max speed(km/h)
|
95
|
|
|
Curb weight(kg)
|
4725
|
|
|
Loading Weight(kg)
|
5000
|
|
|
Engine
|
Model
|
YN38CRD2
|
|
Fuel type
|
Diesel
|
|
|
Horse Power,max
|
115HP
|
|
|
Emission
|
EURO IV
|
|
|
Transmission
|
Model
|
WLY6T46,5 forwards and 1 reverse
|
|
Brake system
|
Service brake
|
Dual circuit compressed air brake
|
|
Parking brake
|
spring energy, compressed air
operating on rear wheels |
|
|
Auxiliary Brake
|
Engine exhaust brake
|
|
|
Color
|
Optional
|
|
|
Tyre
|
8.25R16 Radial tires 6+1 spare
|
|
|
Electrical system
|
Battery
|
2X12V/165Ah
|
|
Alternator
|
28V-1500kw
|
|
|
Starter
|
7.5Kw/24V
|
|
|
Cab
|
2080 Single Row
|
|
