Wrecker Truck Specification
|
Truck Brand
|
SINOTRUK—HOHAN Light Truck
|
|
|
Driving wheel
|
4×2
|
|
|
Driving type
|
Left Hand Driving
|
|
|
Chassis Model
|
ZZ1047D3815C145
|
|
|
Dimension(Lx W x H)(unloaded)(mm)
|
7300*2300*2350
|
|
|
Approaching angle/Departure angle(°)
|
20/14
|
|
|
Overhang(front/rear) (mm)
|
1160/2035
|
|
|
Wheel base (mm)
|
3800
|
|
|
Max speed(km/h)
|
90
|
|
|
Curb weight(kg)
|
1975
|
|
|
Loading Weight(kg)
|
5000
|
|
|
Engine
|
Model
|
4102, 4- stroke direct injection diesel engine, 4 cylinders in line with water cooling
|
|
Fuel type
|
Diesel
|
|
|
Horse Power, max(kw/rpm)
|
116HP
|
|
|
Displacement(L)
|
3.76
|
|
|
Emission
|
EURO III
|
|
|
Fuel tanker capacity (L)
|
Standard
|
|
|
Transmission
|
Model
|
WLY646, 6 forwards and 1 reverse
|
|
Brake system
|
Service brake
|
Dual circuit compressed air brake
|
|
Parking brake
|
spring energy, compressed air operating on rear wheels
|
|
|
Front axle
|
2.7
|
|
|
Rear axle
|
7.2
|
|
|
Color
|
Optional
|
|
|
Tyre
|
7.50R16 Steel , 6+1 Spare
|
|
|
Cab
|
2080 Cabin with AC.
|
|
|
Platform:
|
5 tons of bodywork, 5 tons of winch, 25 meters of steel wire rope, double-sided linkage operation, 3.5 tons of rear support arm
towing, with checkered plate and pressing plate optional, imported valve, equipped with a set of auxiliary trolleys, yellow electronic warning lights, four Root bundler |
|
