Garbage Truck Introduction
Some of the common types include:
- Front Loader: Used primarily for commercial waste collection, these trucks have large prongs on the front that lift waste containers over the truck to dump their contents into the hopper.
- Rear Loader: These trucks have a rear-opening hopper where garbage is manually loaded, often used for residential waste collection.
- Side Loader: Equipped with automated or semi-automated arms that collect garbage bins from the side of the truck, these trucks are often used in areas with standardized trash bins.
- Roll-off Truck: These trucks are designed to transport large, removable containers (roll-off dumpsters) typically used for construction or industrial waste.
Garbage Truck Parameter
|
Specification
|
|||
|
Brand Name
|
SINOTRUK HOWO
|
||
|
Overall Dimension
|
8500×2500×3000 mm（option）
|
Gross Vehicle Weight
|
16000 kg
|
|
Curb Weight
|
6095 kg
|
Loading Weight
|
6700 kg
|
|
Wheel Base
|
3815 mm(option)
|
Front / Rear Axle
|
2500/4800 kg
|
|
Cabin
|
Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio,
|
||
|
Engine horsepower
|
120HP, EUR II（option）
|
||
|
Max Driving Speed
|
90 km/h
|
||
|
Gear Box
|
5 Forward Gear, 1 Reverse Gear,
|
||
|
Tire
|
7.00R16, steel wire tire, 6pc with 1 spare tire
|
||
|
Garbage Bin
|
Capacity
|
7cbm or 8CBM（option））
|
|
|
Material
|
4mm Carbon Steel for Garbage Bin Body
|
||
|
Design
|
Whole unit with Leakage Proof Design
|
||
|
Ways of Loading
|
Rear Loading with optional Bucket Lifting System
|
||
|
Garbage Compact Ratio
|
1/3 – 1/4
|
||
|
Control System
|
One control Panel on the back, One Control system in back of Cabin
|
||
|
Dispensing System
|
1. Equipped with air-tight dustbin, hydraulic system and operating system.
|
||
|
2. Automatic loading, compressing and discharging, all handled by 1 person
|
|||
|
3. Sewage water collection tank to avoid any pollution during handling.
|
|||
|
4. Large Pressure, Good Leakage Proof, Convenient Operation
|
|||
|
Dependable Security
|
|||
|
5. Electrical Control Panel for compacting system.
|
|||
|
6. Cycling time<14~18s
|
|||
|
Remarks
|
1. Color is optional
|
||
|
2. Customized LOGO painting as per customer request
|
|||
